Full Product Description

The Hunter 10A nozzle is designed for effective watering of areas with a radius of 3 m and is suitable for installation in automatic irrigation systems of private and commercial facilities. The adjustable sector from 0° to 360° makes it possible to precisely adjust the direction of watering to the shape of the lawn, flowerbed or green strip. Hunter's official specs say the 10A has a 15° trajectory, giving it consistent coverage on medium-sized areas.

Hunter 10A is a good choice for those who are looking for a reliable adjustable nozzle with precise fan irrigation and easy adjustment. The PRO series is designed to work with clear irrigation boundaries and produces larger droplets, helping to reduce unwanted overspray. This model is well suited for lawns near the house, landscape compositions and areas where it is important to evenly cover the area without overspending water. The Hunter 10A nozzle is worth buying for systems that require precision, flexibility and stable results.

Technical characteristics

• Radius: 3m;
• Recommended working pressure: 2.1 bar; 200 kPa;
• The new fan sprayer of the PRO-Spray® series, model PRS30, is designed for precise pressure regulation of 2.1 bar; 210 kPa;
• Application: Private / Commercial.

Advantages

• Sharply defined, clear edges;
• Exact compliance with watering norms at a distance of 2.4 - 5.2 m;
• Convenient grip for adjustment;
• Large drops of water – effective in windy weather;
• Even watering;
• New adjustable nozzles of 1.2 m and 1.8 m provide additional operational flexibility;
• Different colors for clear identification;
• Angle: 0° - 360°.

• 8A & 10A

  ---

  			NOZZLE 8A BROWN • 2.4 m Radius Adjustment 0° - 360 Trajectory 0°					NOZZLE 10A RED • 3.0 m Radius Adjustment 0° - 360 Trajectory 15°
  Irrigation sector	Pressure		Radius	Expense		Rate mm/h		Radius	Expense		Rate mm/h
  	bar	kPa	m	m3/h	l/min			m	m3/h	l/min
  45°	1.0	100	2.0	0.04	0.62	77	89	2.6	0.04	0.68	49	56
  	1.5	150	2,2	0.04	0.72	72	83	2.8	0.05	0.80	49	57
  	2.1	210	2,4	0.05	0.83	67	77	3.0	0.06	0.94	49	56
  	2.5	250	2.6	0.05	0.91	63	73	3.2	0.06	1.06	48	56
  	3.0	300	2.9	0.06	1.01	59	68	3.5	0.07	1.18	47	54
  90°	1.0	100	2.0	0.07	1.24	77	89	2.6	0.08	1.35	49	56
  	1.5	150	2,2	0.09	1.44	72	83	2.8	0.10	1.61	49	57
  	2.1	210	2,4	0.10	1.65	67	77	3.0	0.11	1.89	49	56
  	2.5	250	2.6	0.11	1.82	63	73	3.2	0.13	2.11	48	56
  	3.0	300	2.9	0.12	2.02	59	68	3.5	0.14	2.37	47	54
  120°	1.0	100	2.0	0.10	1.66	77	89	2.6	0.11	1.80	49	56
  	1.5	150	2,2	0.11	1.92	72	83	2.8	0.13	2.14	49	57
  	2.1	210	2,4	0.13	2.20	67	77	3.0	0.15	2.52	49	56
  	2.5	250	2.6	0.15	2.43	63	73	3.2	0.17	2.82	48	56
  	3.0	300	2.9	0.16	2.69	59	68	3.5	0.19	3,16	47	54
  180°	1.0	100	2.0	0.15	2.49	77	89	2.6	0.16	2.71	49	56
  	1.5	150	2,2	0.17	2.87	72	83	2.8	0.19	3.21	49	57
  	2.1	210	2,4	0.20	3.30	67	77	3.0	0.23	3.78	49	56
  	2.5	250	2.6	0.22	3.65	63	73	3.2	0.25	4.23	48	56
  	3.0	300	2.9	0.24	4.03	59	68	3.5	0.28	4.73	47	54
  240°	1.0	100	2.0	0.20	3.32	77	89	2.6	0.22	3.61	49	56
  	1.5	150	2,2	0.23	3.83	72	83	2.8	0.26	4,28	49	57
  	2.1	210	2,4	0.26	4.40	67	77	3.0	0.30	5.03	49	56
  	2.5	250	2.6	0.29	4.86	63	73	3.2	0.34	5.64	48	56
  	3.0	300	2.9	0.32	5.38	59	68	3.5	0.38	6.31	47	54
  270°	1.0	100	2.0	0.22	3.73	77	89	2.6	0.24	4.06	49	56
  	1.5	150	2,2	0.26	4.31	72	83	2.8	0.29	4.82	49	57
  	2.1	210	2,4	0.30	4.95	67	77	3.0	0.34	5.66	49	56
  	2.5	250	2.6	0.33	5.47	63	73	3.2	0.38	6.34	48	56
  	3.0	300	2.9	0.36	6.05	59	68	3.5	0.43	7,10	47	54
  360°	1.0	100	2.0	0.30	4.97	77	89	2.6	0.32	5.41	49	56
  	1.5	150	2,2	0.34	5.75	72	83	2.8	0.39	6.43	49	57
  	2.1	210	2,4	0.40	6.61	67	77	3.0	0.45	7.55	49	56
  	2.5	250	2.6	0.44	7.29	63	73	3.2	0.51	8.45	48	56
  	3.0	300	2.9	0.48	8.07	59	68	3.5	0.57	9.47	47	54
