Hunter MP82090 nozzle — MP800 series rotary nozzle, radius 4.6–7.3 m, sector 90°–210°
Hunter MP82090 is an innovative rotating sprinkler that expands the capabilities of the popular MP800 series. It provides precise irrigation intensity of 20 mm/h at a radius of up to 7.3 meters. This is an ideal solution for medium-density soils and small areas where faster moistening is required compared to standard MP Rotator models. The sprinkler stands out with high wind resistance, double retraction for protection against dirt, and exceptional even water distribution.
-
Delivery and Payment
-
Warranty
-
Return and Exchange
Full Product Description
Hunter MP82090: A new level of efficiency in the MP800 line
Nozzle Hunter MP82090 is a new development that allows designing irrigation systems with increased intensity over larger areas. If earlier the MP800 series was limited to a small radius (SR model - 1.8 m), then today MP820 allows achieving coverage of up to 7.3 m with unchanged precipitation accuracy of 20 mm/h.
The main advantages of the model:
- Optimal irrigation rate: The intensity of 20 mm/h is twice as high as the standard MP Rotator (10 mm/h). This makes the MP820 model an ideal choice for gentle slopes and soils of medium density, where it is important to provide sufficient moisture without creating runoff.
- Wind-resistant technology: A multi-stream trajectory creates large droplets that are resistant to wind, preventing the formation of water mist and ensuring that water is delivered directly to the root zone.
- Double-pop mechanism (Double-Pop): A unique mechanism protects the nozzle from debris and sand from the outside, as the nozzle extends from the body only after the rod is fully raised.
- Adjustment flexibility: The irrigation sector is easily adjustable within the range of 90° to 210°, which allows installing sprinklers both in corners and along paths or fences.
Scope of application:
Hunter MP82090 nozzles have a wide range of applications in automatic irrigation of private gardens and park areas. They are ideal for irrigating:
- Lawns of medium size.
- Low-growing shrubs.
- Vegetable crops.
Installation and adjustment instructions:
- Installation: Unscrew the flushing plug from the sprinkler rod and screw in the MP82090 nozzle clockwise.
- Alignment: Set the left boundary of irrigation (fixed edge) by turning the rod by hand so that the mark on the nozzle points to the outermost left point of the working area.
- Sector adjustment: While the nozzle is working, rotate the upper metal ring to expand or narrow the sector from 90° to 210°.
- Radius adjustment: Use the screw in the center of the nozzle to reduce the radius by up to 25%. For maximum accuracy, it is recommended to use the proprietary Hunter MP Tool.
Technical characteristics:
Nozzle type
Rotary (MP Rotator)
Irrigation radius
4.6 – 7.3 m
Irrigation sector
90° – 210° (adjustable)
Irrigation intensity
approximately 20 mm/h
Recommended pressure
2.1 – 3.8 bar (210 – 380 kPa)
Features
Color coding, removable filter
Tip from Agras.ua: To achieve maximum uniformity and water savings on dense soils, choose standard MP Rotator models with an intensity of 10 mm/h. Use the MP800 series (20 mm/h) where it is necessary to reduce the operating time of the irrigation zone.
MP-820 Radius: 1.8-7.3 m Adjustable sector and full rotation
Gray with black: 90–210°
Gray with green: 210–270°
Gray with red: 360 °
